COB Mini Spot

NEW

Categories: , ,
General Details

  • Single, powerful COB (chip on board) LED design package
  • Sleek and compact MR11 size body
  • Available in 10W, 5W and 3.5W
  • Very quiet fan (10W, 5W)
  • MO track compatible
  • Suitable for floodlights and all kinds of spotlight application

Model: CMS-xxW-yy (xx= Watts) (yy= Lens)
Size: 48mm(Dia.)(1.88″) x
(10W/5W) Fan- 66.04mm(H)(2.60″)
(3.5W) No Fan- 53.45mm(H)(2.09″)

Power Consumption:
(10W)- 10.6W per fixture
(5W)- 6.7W per fixture
(3.5W)- 4.32W per fixture

Output Lumen: 1270lm per fixture
(10W)- 1270lm per fixture
(5W)- 640lm per fixture
(3.5W)- 480lm per fixture

Input Voltage: 24 VDC
LED Types: COB LED
CRI: >90
Lamp Life: 50,000 Average life hours
Available Color (K): 3000, 3500, 4000 (Custom color available)
Lens:
Cone Lens (CL): 29°, 50° (fwhm)
Reflectors (RF): 21°, 33°, 45°, 57°

Dimmable: Yes
Cooling: Fan cooling, Heat sink
Application: Interior use only
Accessories: Snoot, Louver, Diffuser(253/132) are available

IES File: Available upon request
Diagram: Available upon request

Customization

MO Track

Accessory

Lens (fwhm):

23°

29°

50°















Lighting Effect (6 inch distance)

23°

29°

50°















Snoot & Louver















Diffuser

132

253

Cut Sheet and IES
